产品介绍
适用范围Application
● 适用于爆炸性环境1区、2区；
● 适用于ⅡA、ⅡB、ⅡC类爆炸性气体环境；
● 适用于可燃性粉尘环境21区～22区；
● 适用于温度组别为T1～T6的环境；
● 适用于石油采炼、储存、化工、医药、军 工等危险环境及海洋石油平台、油轮等场所工作及场景照明之用。
● It is suitable for Zone1 and 2 of explosive atmospheres;
● It is suitable for ClassⅡA, ⅡB, ⅡC of explosive gas atmospheres;
● It is suitable for Zone 21~ 22 of combustible dust atmospheres;
● It is suitable for temperature group T1 ~ T6 environment;
● It is suitable for lighting in oil refining, storage, chemical, pharmaceutical, military and other hazardous environments as well offshore oil platforms, oil tankers and other work places and scene purposes.
技术数据Technical data
● 防爆标志：与配装灯具相应规格的防爆标志
● 额定工作电压: AC220V
● Explosion calegory: Explosion-proof mark with corresponding
● Rated voltage: AC220V
产品特点Product features
● 灯杆材质采用Q235优质碳素钢；
● 灯杆抗风不小于40m/s设计，灯杆不直度为1/1000,不圆度不大于2mm，触电防护1级；
● 进口线为2-G11/4，出线口为G3/4;
● 灯杆底部门盖专用工具开启，避免非工作人员开启；
● 根据买方要求，可配置电气控制箱或接线箱；
● 防爆灯具与灯杆之间采用专用链接套固定，链接牢靠可靠；
● 钢管或电缆布线。
● Q235 high quality carbon steel is used for the lamp pole;
● The wind resistance of lamp pole shall be designed to be no less than 40m / s, the straightness of lamp pole shall be 1 / 1000, the roundness shall be no more than 2mm, and the electric shock protection shall be level 1;
● The inlet line is 2-g11 / 4, and the outlet is G3 / 4;
● Special tools for the door cover at the bottom of the light pole shall be opened to prevent non staff from opening;
● According to the buyer's requirements, the electrical control box or junction box can be configured;
● The special link sleeve is used to fix the explosion-proof lamp and the lamp pole, and the link is firm and reliable;
● Steel pipe or cable wiring.
