产品介绍
适用范围Application
适用于爆炸性环境1区、2区；
适用于ⅡA、ⅡB类爆炸性气体环境；
适用于温度组别为T1～T4的环境；
适用于石油采炼、储存、化工、医药、军 工等危险环境及海洋石油平台油轮等场所。
It is suitable for Zone1 and 2 of explosive atmospheres;
It is suitable for Class ⅡA, ⅡB of explosive gas atmospheres;
It is suitable for temperature group T1 ~ T4 environment;
It is for oil refining, storage, chemical, pharmaceutical, military and other hazardous environments as well offshore oil platforms and tankers and other places.
技术数据Technical data
防爆标志：Ex db IIB T4 Gb;Ex tb IIIC T80℃ Db
防护等级：IP54
额定工作电压：AC220V/380V
防腐等级：WF2
Explosion category: Ex db IIB T4 Gb;Ex tb IIIC T80℃ Db
Protection category: IP54
Rated voltage: AC220V/380V
Corrosion-proof class: WF2
产品特点Features
外壳采用铝合金铸造成型，表面高压静电喷涂；
电加热管外壳为不锈钢，内部采用耐高温绝缘胶压力注射定型电热体；
法兰式安装；
可根据用户要求特殊定制；
The shell is made of aluminum alloy and sprayed with high voltage electrostatic;
The shell of the electric heating tube is made of stainless steel, and the inner part is made of high temperature resistant insulating glue pressure injection molding electric heater; injected electro themal part, the case is made of aluminium alloy；
Flange mounting;
It can be made according to user requirements
