产品介绍
适用范围Application
适用于爆炸性环境1区、2区；
适用于ⅡA、ⅡB、ⅡC类爆炸性气体环境；
适用于可燃性粉尘环境21区~22区；
适用于温度组别为T1~T6的环境；
适用于石油采炼、储存、化工、医药、军 工等危险环境及海洋石油平台油轮等场所。
It is suitable for Zone1 and 2 of explosive atmospheres;
It is suitable for Class ⅡA, ⅡB, ⅡC of explosive gas atmospheres;
It is suitable for Zone 21~22 of combustible dust atmospheres;
It is suitable for temperature group T1~T6 environment;
It is for oil refining, storage, chemical, pharmaceutical, military and other hazardous environments as well offshore oil platforms and tankers and other places.
技术数据Technical data
防爆标志：Ex eb IIC T4 Gb;Ex tb IIIC T80℃ Db Ex eb IIC T6 Gb;
Ex tb IIIC T80℃ Db
防护等级：IP66
额定工作电压：AC220V/380V
端子电流：≤400A
防腐等级：WF2
Explosion category: Ex eb IIC T4 Gb;
Ex tb IIIC T80℃ Db Ex eb IIC T6 Gb;
Ex tb IIIC T80℃ Db
Protection category: IP66
Rated voltage: AC220V/380V
Terminal current: ≤400A
Corrosion-proof class: WF2
产品特点Features
外壳采用玻璃纤维增强不饱和聚酯树脂压制而成，外型美观且具有抗静电耐冲击及热稳定性好，耐腐蚀等优良性能；
结合面采用曲路密封结构，具有较强的防水、防尘性能；
外露紧固件均用不锈钢材质，采用防掉式设计，便于用户安装、维护；
内装端子数、引入口方向、数量及规格，可按用户要求任意变化；
可用于电气控制线路中，作为各种电气设备的分线、接线用，也可用作自控、通讯信号和电源线的连接；
可根据用户要求特殊定制，可选铸铝合金、优质钢板或不锈钢板。
Shell is made of glass fiber reinforced unsaturated polyester resin with a beautiful appearance, corrosion resistance, anti-static, impact resistance and good thermal stability and excellent performance;
Jointing point adopts blend sealing structure, it is with perfect water&dust proof functions;
Exposed fasteners are made of stainless steel and use anti-off design and are easy to install and maintain by users;
Built-in terminal numbers, inlet direction, quantity and specifications can change users according to user requirements;
It can be used for sub-line or wiring of various electrical equipment in electrical control circuit and also can be used as connection of auto control, communication signal and power cable;
It can be customized according to the user's requirements, including cast aluminum alloy, high-quality steel plate or stainless steel plate.
