产品介绍
适用范围Application
适用于爆炸性环境1区、2区；
适用于ⅡA、ⅡB、ⅡC类爆炸性气体环境；
适用于可燃性粉尘环境21区～22区；
适用于温度组别为T1~T6的环境；
适用于石油采炼、储存、化工、医药、军 工等危险环境及海洋石油平台油轮等场所。
It is suitable for Zone1 and 2 of explosive atmospheres;
It is suitable for Class ⅡA, ⅡB, ⅡC of explosive gas atmospheres;
It is suitable for Zone 21~22 of combustible dust atmospheres;
It is suitable for temperature group T1 ~ T6 environment;
It is for oil refining, storage, chemical, pharmaceutical, military and other hazardous environments as well offshore oil platforms and tankers and other places.
技术数据Technical data
防爆标志：Ex db IIC T6 Gb;Ex tb IIIC T80℃ Db
防护等级：IP66
额定工作电压：AC220V/380V
额定电流：≤400A
防腐等级：WF2
Explosion category: Ex db IIC T6 Gb;Ex tb IIIC T80℃ Db
Protection category: IP66
Rated voltage: up to AC220V/380V
Rated current: ≤400A
Corrosion-proof class: WF2
产品特点 Features
外壳采用铝合金压铸成型,表面静电喷涂；
壳体可根据客户要求采用不锈钢制作；
引入口方向可根据要求确定，并可根据用户 要求配装BDM系列电缆夹紧密封接头；
接线箱引入口规格常规为英制管螺纹，可根 据用户要求加工公制螺纹或NPT等螺纹，订 货时请注明。
Shell is formed of aluminum alloy, surface is high voltage electrostatic spraying;
Housing can be made of stainless steel according to customer requirements;
Inlet direction can be determined according to customer requirements and also can be equipped with BDM series of cable clamping sealing connectors;
Common inlet specifications of junction boxes are BSP and also can be made of metric thread or NPT thread according to user requirements. It should be indicated please when ordering.
