产品介绍
适用范围Application
适用于爆炸性环境1区、2区；
适用于ⅡA、ⅡB类爆炸性气体环境；
适用于可燃性粉尘环境21区～22区；
适用于温度组别为T1~T6的环境；
适用于石油采炼、储存、化工、医药、军 工等危险环境及海洋石油平台油轮等场所。
It is suitable for Zone1 and 2 of explosive atmospheres;
It is suitable for Class ⅡA, ⅡB of explosive gas atmospheres;
It is suitable for Zone 21~22 of combustible dust atmospheres;
It is suitable for temperature group T1 ~ T6 environment;
It is for oil refining, storage, chemical, pharmaceutical, military and other hazardous environments as well offshore oil platforms and tankers and other places
技术数据Technical data
防爆标志：Ex db IIB T6 Gb;Ex tb IIIC T80℃ Db
防护等级：IP66
额定工作电压：AC220V/380V
额定电流：≤100A
防腐等级：WF2
Explosion category: Ex db IIB T6 Gb;Ex tb IIIC T80℃ Db
Protection category: IP66
Rated voltage: AC220V/380V
Rated current: ≤100A
Corrosion-proof class: WF2
产品特点 Features
外壳采用铝合金压铸成型,表面高压静电喷涂；
壳体可根据客户要求采用碳钢、不锈钢制作；
引入口方向可根据要求确定。
The shell is made of aluminum alloy by die casting, and the surface is sprayed by high voltage static electricity;
The shell can be made of carbon steel and stainless steel according to customers' requirements;
The direction of the inlet can be determined according to the requirements.
